SHIMANO GRX TUBELESS WHEEL-WH-RX870-TL-700C
SHIMANO GRX TUBELESS WHEEL-WH-RX870-TL-700C
Couldn't load pickup availability
Share
The new GRX wheel supports gravel rides that are faster, further, and more fun. Wider tires need wider rims to maintain lateral tire stability at low air pressures. Shimano studied the complicated relationship between tire size, rim width, air pressure, and tire lateral rigidity to optimize the GRX rim width for 32-50c tires. In addition, we pursued the best balance of rim weight, strength, and profile in order to deliver an exceptional gravel wheel.
BENEFIT
First SHIMANO GRX carbon wheel
BENEFIT
32 mm height full carbon rim
BENEFIT
Internal rim width: 25 mm
BENEFIT
Recommended tire size: 32-622 - 50-622
BENEFIT
Road 11 & 12-speed compatible
Model No: WH-RX870-TL-F12-700C
Series: GRX
Model name: WH-RX870-TL
Specification: F12-700C
Color 1 Hub shell: Black
Brake type: CENTER LOCK disc brake
O.L.D. (mm): 100
Wheel size: 622 x 25C (700C)
Tire Type: Tubeless
Tire Recommended size: 32-622 - 50-622
Rim Height (mm): 32
Rim Internal width (mm): 25
Rim External width (mm): 30.7
Rim Requires rim tape: ✔
Spokes Number: 24
Spokes Straight pull: ✔
Spokes Bladed: ✔
Spokes Butted: ✔
Spokes Diameter (mm): 2.0-1.6-2.0
Axle fixing method: E-THRU
Disc mount CENTER LOCK: ✔
Disc mount 140 mm disc brake rotor compatible: ✔
Seal Hub: Contact
Reflector JIS/CPSC: CATEYE RR-550-WUW SW
Reflector AS: CATEYE RR-550-WUA SW
Reflector DIN: CATEYE RR-317-WUA SW
Average weight: 639
Color: Black
