SHIMANO DURA ACE CARBON WHEELSET-WH-R9270-C60-HR-TL
SHIMANO DURA ACE CARBON WHEELSET-WH-R9270-C60-HR-TL
Couldn't load pickup availability
Share
Like the entire DURA-ACE wheel family, the new C60 started with a blank slate. Different from the C36 and C50, the C60 has a specific front hub design using Shimano's OPTBAL 2:1 spoke pattern to enhance lateral rigidity. The C60 also receives stiffer spokes, 1.8 mm instead of 1.5 mm. Tested by our professional athletes, this focus on the lateral rigidity of C60 allows you to push harder in corners and when maneuvering at higher speeds. Lastly the new wind-tunnel tested, deep section rims feature a faster, more stable cross-section that time trialists, triathletes, and sprinters alike will enjoy.
BENEFIT
HR: High-Rigidity ver. +20% increased lateral rigidity for powerful riders and sprinters
BENEFIT
60 mm height full carbon rim
BENEFIT
Internal rim width: 21 mm
BENEFIT
DIRECT ENGAGEMENT
BENEFIT
Compatible only with Shimano road 12-speed cassette sprockets
Model No: WH-R9270-C60-HR-TL-R
Series: DURA-ACE
Model name: WH-R9270-C60-HR-TL
Specification: R
Color 1 Hub shell: Series color
Brake type: CENTER LOCK disc brake
Rear speeds: 12
O.L.D. (mm): 142
Wheel size: 622 x 21C (700C)
Tire Type: Tubeless
Tire Recommended size: 25-622 - 32-622
Rim Height (mm): 60
Rim Internal width (mm): 21
Rim External width (mm): 28
Rim Requires rim tape: ✔
Spokes Number: 24
Spokes Straight pull: ✔
Spokes Bladed: ✔
Spokes Butted: ✔
Spokes Diameter (mm): 2.0-1.8-2.0
Axle fixing method: 12 mm E-THRU
Spline type HG spline L2 (ROAD 12-speed dedicated): ✔
Engagement type: Direct engagement
Disc mount CENTER LOCK: ✔
Disc mount 140 mm disc brake rotor compatible: ✔
OPTBAL (2:1): ✔
D2 rim: ✔
Seal Hub: Contact
Seal FREEHUB body: Contact
Compatible spoke protector: CP-WR92C
Reflector JIS/CPSC: CATEYE RR-550-WUW SW
Reflector AS: CATEYE RR-550-WUA SW:
Reflector DIN: CATEYE RR-317-WUA SW
Average weight: 858
Color: Series color
